Description
Polymer Systems Granulator 1624 SPL & Auger Feeder w/ Magnetic Separator CCR16632T
If video viewport is not working, you can view the video here:
Brand: Polymer Systems
Model: 1624 SPL
Serial: 1624 SPL 2885 91
Volts: 460
Phase: 3
Hz: 60
HP: 30 Amps: 38
Control Circuit: 115 Volts
Electric Motor: Lincoln A.C. Motor
Model: Lincguard Dripproof
HP: 50
RPM: 1770
Volts: 230 / 460
Phase: 3
Hz: 60
Amps: 125 / 62.5
Product Inlet Dimensions: 24 In. W x 16 In. H
Product Outlet Dimensions: 24 In. W x 8 In. H
Overall Dimensions: 67.5 In. L x 60 In. W x 91.5 In. H
Auger Feeder w/ Magnetic Separator
Overall Dimensions: 132 In. L x 32 In. W x 46 In. H
Magnets Dimensions: 35 In. W x 15 In. H
Magnet Qty: 2
Auger Dia.: 6 In.
Auger Length: 120 In.
Electric Motor: WEG Motor
Phase: 3
Volts: 460
Grove Gear: Iron Man
Model: GR8420321
Output HP: 4.39
Out-Torque In-Lbs.: 6170
CCR16632
